Display Hardware Status
Type option, press Enter.
1=Display hardware resource information details
OPT Name PCI/SCSI Location Description Status
--- ------ -------------------------- ------------------------- ---------------
0000:02:04.0.2/ PCI-X SCSI RAID Adapter Operational
0000:02:04.0.2/1:14:0 Advanced Function Disk Active
0000:02:04.0.2/1:6:0 Advanced Function Disk Active
0000:02:04.0.2/1:8:0 Advanced Function Disk Active
0000:02:04.0.2/1:9:0 Advanced Function Disk Active
sdt 0000:02:04.0.2/255:0:0 RAID 5 Disk Array Active
0000:02:04.0.2/1:10:0 RAID 5 Array Member Active
0000:02:04.0.2/1:11:0 RAID 5 Array Member Active
0000:02:04.0.2/1:12:0 RAID 5 Array Member Active
0000:02:04.0.2/1:13:0 RAID 5 Array Member Active
sdb 0000:02:04.0.2/255:0:2 RAID 0 Disk Array Active
0000:02:04.0.2/1:4:0 RAID 0 Array Member Active
sdc 0000:02:04.0.2/255:0:3 RAID 0 Disk Array Active
0000:02:04.0.2/1:3:0 RAID 0 Array Member Active
sdd 0000:02:04.0.2/255:0:4 RAID 0 Disk Array Active
More...
e=Exit q=Cancel r=Refresh t=Toggle f=PageDn b=PageUp
If the message on your screen indicates your newly installed card, shown in the example as PCI-X SCSI
RAID Adapter , is Not Operational instead of Operational or if it is not listed, shut down your machine. Go
to “Installing the PCI-X Dual Channel Ultra320 SCSI RAID Adapter using the ipr Device Driver” on page 15
to ensure that the PCI-X Dual Channel Ultra320 SCSI RAID Adapter is installed correctly. Then return to
this section, and repeat this hardware installation procedure.
Chapter 7. Installing and Setting Up Software for the PCI-X Dual Channel Ultra320 SCSI RAID Adapter (Linux ) 19
