Insignia IS-EDPLTV42 User Manual
Page 9

8
IS-EDPLTV42 42-inch ED TV
www.insignia-products.com
6
Left A/V 1 audio input
jack
7
Right A/V 1 audio input
jack
8
Left A/V 2 audio input
jack
9
Right A/V 2 audio input
jack
10
Headphone jack
11
PC audio input jack
12
Video output jack
13
75 OHM connector
14
S-Video jack
15
Video 1 input
16
Video 2 input
17
YPbPr/YCbCr input
18
Power cord
19
VGA input
20
DVI Input (with HDCP)
21
RS232C debug input
22
AC power connector
Connector
