Ice-O-Matic ICE0400 - Manual (Page 9)

ICE Series Service Parts Air Cooled
Item
No. ICE0250 ICE0400 ICE0406 ICE0500 ICE0606 Description
1 9181117-11 9181086-11 9181086-12 9181085-12 9181112-11 Compressor
1 9181121-11 Compressor Beg. Rev 2
2 9151123-03 9151123-03 9151023-04 9151123-03 9151023-04 Hot Gas Valve Coil
3 9151123-01 9151123-01 9151123-01 9151123-01 9151123-01 Hot Gas Valve Body
4 9041094-01 9041094-01 9041094-01 9041094-01 9041094-01 Low Pressure Control
5 9151004-02 9151004-02 9151004-02 9151004-02 9151004-02 Filter Drier
6 9041086-01 9041086-01 9041086-02 9041086-01 9041086-02 Purge Valve
7 9091074-01 9091074-01 9091074-01 9091074-01 9091074-01 Drop Adapter
8 9091083-01 9091083-01 9091083-01 9091083-01 9091083-01 Water Inlet Fitting
9 9091119-01 9091119-01 9091119-01 9091119-01 9091119-01 Purge Drain Fitting
10 9021010-03 9021010-03 9021010-03 9021010-03 9021010-03 Clamp
11 9151006-16 9151006-08 9151006-08 9151006-08 9151006-08 Expansion Valve
11 9151154-01 Expansion Valve (Beg. Ser. F3)
11 9151149-01 9151149-01 9151149-01 Expansion Valve (Beg. Ser. K1)
11 9151151-01 Expansion Valve (Beg. Ser. B2)
12 9051280-01 9051280-01 9051280-01 9051280-01 9051280-01 Purge Drain Hose
13 6021032-01 6021032-01 6021032-01 6021032-01 6021032-01 Tube ( 2.17 Ft.)
14 9021010-04 9021010-04 9021010-04 9021010-04 9021010-04 Clamp
15 9041087-03 9041087-03 9041087-03 9041087-03 9041087-03 High Temp Safety
16 9141104-01 9141106-01 9141106-01 9141113-01 9141113-01 Air Condenser
9141120-01 Air Cond Beg Ser E217-07212-Z
9141120-01 Air Cond Beg Ser F2
17 9161089-02 9161089-02 9161089-03 9161089-02 9161089-03 Fan Motor
17 9161078-01 Fan Motor Beg. 07111280012633
18 9131332-02 9131332-02 9131332-02 9131333-02 9131332-02 Fan Blade
18 9131383-01 Fan Blade Beg. 07111280012633
19 3012527-01 3012527-01 3012527-01 3012527-01 3012527-01 Fan Motor Bracket
19 3013252-01 Fan Motor Brkt Beg 07111280012633
20 3012526-01 3012526-01 3012526-01 3012526-01 3012526-01 Fan Shroud
Item
No. ICE0305 ICE0405 ICE0605
1 9101088-11 9181088-11 9181112-12
2 9151023-04 9151023-04 9151023-04
3 9151123-01 9151123-01 9151123-01
4 9041094-01 9041094-01 9041094-01
5 9151004-02 9151004-02 9151004-02
6 9041086-02 9041086-02 9041086-02
7 9091074-01 9091074-01 9091074-01
8 9091083-01 9091083-01 9091083-01
9 9091119-01 9091119-01 9091119-01
10 9021010-03 9021010-03 9021010-03
11 9161006-16 9161006-08 9161006-08
11 9151154-01
11 9151149-01
11 9151151-01
12 9051280-01 9051280-01 9051280-01
13 6021032-01 6021032-01 6021032-01
14 9021010-04 9021010-04 9021010-04
15 9041087-03 9041087-03 9041087-03
16 9141106-01 9141006-01 9141113-01
16 9141004-01
17 9161108-03 9161089-03 9161089-03
18 9131333-01 9131332-02 9131332-02
19 3012527-01 3012527-01 3012527-01
20 3012526-01 3012526-01 3012526-01
Fan Motor
Fan Blade
Fan Motor Bracket
Fan Shroud
Purge Drain Hose
Tube ( 2.17 Ft.)
Clamp
High Temp Safety
Air Condenser
Air Cond Beg Rev 2
Purge Drain Fitting
Clamp
Expansion Valve
Expansion Valve (Beg. Ser. F3)
Expansion Valve (Beg. Ser. K1)
Expansion Valve (Beg. Ser. B2)
Hot Gas Valve Body
Low Pressure Control
Filter Drier
Purge Valve
Drop Adapter
Water Inlet Fitting
Model Number
Model Number
Description
Compressor
Hot Gas Valve Coil
Page 7
