ICE Series Service Parts Water Cooled
Item
No. ICE0250 ICE0400 ICE0406 ICE0500 ICE0606 Description
1 9181117-11 9181086-11 9181086-12 9181085-12 9181112-11 Compressor
1 9181121-11 Compressor Beg. Rev 2
2 9151123-03 9151123-03 9151023-04 9151123-03 9151023-04 Hot Gas Valve Coil
3 9151123-01 9151123-01 9151123-01 9151123-01 9151123-01 Hot Gas Valve Body
4 9041094-01 9041094-01 9041094-01 9041094-01 9041094-01 Low Pressure Control
5 9151004-02 9151004-02 9151004-02 9151004-02 9151004-02 Filter Drier
6 9041086-01 9041086-01 9041086-02 9041086-01 9041086-02 Purge Valve
7 9091074-01 9091074-01 9091074-01 9091074-01 9091074-01 Drop Adapter
8 9091083-01 9091083-01 9091083-01 9091083-01 9091083-01 Water Inlet Fitting
9 9091119-01 9091119-01 9091119-01 9091119-01 9091119-01 Purge Drain Fitting
10 9021010-03 9021010-03 9021010-03 9021010-03 9021010-03 Clamp
11 9151006-21 9151006-08 9151006-08 9151006-08 9151006-08 Expansion Valve
11 9151154-01 Expansion Valve (Beg. Ser. F3)
11 9151149-01 9151149-01 9151149-01 Expansion Valve (Beg. Ser. K1)
11 9151151-01 Expansion Valve (Beg. Ser. B2)
12 9051280-01 9051280-01 9051280-01 9051280-01 9051280-01 Purge Drain Hose
13 6021032-01 6021032-01 6021032-01 6021032-01 6021032-01 Tube ( 2.17 Ft.)
14 9021010-04 9021010-04 9021010-04 9021010-04 9021010-04 Clamp
15 9041087-03 9041087-03 9041087-03 9041087-03 9041087-03 High Temp Safety
16 9141061-01 9141023-01 9141024-01 9141024-01 9141024-01 Water Condenser
17 9041059-01 9041059-01 9041059-01 9041059-01 9041059-01 Water Valve
18 9091063-02 9091063-02 9091063-02 9091063-02 9091063-02 Drop Adapter 1/2"
Item
No. ICE0305 ICE0405 ICE0605
1 9101088-11 9181088-11 9181112-12
2 9151023-04 9151023-04 9151023-04
3 9151123-01 9151123-01 9151123-01
4 9041094-01 9041094-01 9041094-01
5 9151004-02 9151004-02 9151004-02
6 9041086-02 9041086-02 9041086-02
7 9091074-01 9091074-01 9091074-01
8 9091083-01 9091083-01 9091083-01
9 9091119-01 9091119-01 9091119-01
10 9021010-03 9021010-03 9021010-03
11 9161006-16 9151006-08 9151006-08
11 9151154-01
11 9151149-01
11 9151151-01
15 9041087-03 9041087-03 9041087-03
16 9141061-01 9141024-01 9141024-01
17 9041059-01 9041059-01 9041059-01
18 9091063-02 9091063-02 9091063-02
Water Condenser
Water Valve
Drop Adapter 1/2"
Clamp
Expansion Valve
Expansion Valve (Beg. Ser. F3)
Expansion Valve (Beg. Ser. K1)
Expansion Valve (Beg. Ser. B2)
High Temp Safety
Low Pressure Control
Filter Drier
Purge Valve
Drop Adapter
Water Inlet Fitting
Purge Drain Fitting
Model Number
Model Number
Description
Compressor
Hot Gas Valve Coil
Hot Gas Valve Body
