ICE Series Service Parts Front Interior
Item
No. ICE0250 ICE0400 ICE0406 ICE0500 ICE0606 Description
1 2021524-01 2021524-01 2021524-01 2021524-01 2021524-01 Left Hand Frame Panel
2 2021523-01 2021523-01 2021523-01 2021523-01 2021523-01 Right Hand Frame Panel
3 2051156-81 2051148-81 2051148-81 2051148-81 2051148-81 Evaporator-Full Cube
3 2051156-82 2051148-82 2051148-82 2051148-82 2051148-82 Evaporator-Half Cube
4 9051154-07 9051154-08 9051154-08 9051154-08 9051154-08 Evaporator Splash Curtain
5 2041338-01 2041338-01 2041338-01 2041338-01 2041338-01 Water Distribution Tube
6 9031122-01 9031122-01 9031122-01 9031122-01 9031122-01 Thumb Screw
7 9031004-19 9031004-19 9031004-19 9031004-19 9031004-19 Rubber Washer
8 9041051-04 9041051-04 9041051-04 9041051-04 9041051-04 High Pressure Control
9 9021010-04 9021010-04 9021010-04 9021010-04 9021010-04 Clamp
10 9051142-02 9051142-01 9051142-01 9051142-01 9051142-01 Water Pump Tube
11 9161076-01 9161076-01 9161076-02 9161076-01 9161076-02 Water Pump
12 9131111-01 9131111-01 9131111-01 9131111-01 9131111-01 Float
13 6021032-01 6021032-01 6021032-01 6021032-01 6021032-01 Water Float Tube (26")
14 9051001-09 9051001-09 9051001-09 9051001-09 9051001-09 Snap Bushing
15 9051537-01 9051537-01 9051537-01 9051537-01 9051537-01 Water Return Trough
16 9031046-24 9031046-24 9031046-24 9031046-24 9031046-24 Water Return Trough Screw
17 9091086-02 9091086-02 9091086-02 9091086-02 9091086-02 Valve Core
18 9091086-03 9091086-03 9091086-03 9091086-03 9091086-03 Valve Cap
19 9131026-02 9131026-02 9131026-02 9131026-02 9131026-02 Caplug
20 3012747-01 N/A N/A N/A N/A Bracket Curtain Stopper
21 9031141-01 9031141-01 9031141-01 9031141-01 9031141-01 Plastic Nut Insert
Item
No. ICE0305 ICE0405 ICE0605
1 2021524-01 2021524-01 2021524-01
2 2021523-01 2021523-01 2021523-01
3 2051156-81 2051148-81 2051148-81
3 2051156-82 2051148-82 2051148-82
4 9051154-07 9051154-08 9051154-08
5 2041338-01 2041338-01 2041338-01
6 9031122-01 9031122-01 9031122-01
7 9031004-19 9031004-19 9031004-19
8 9041051-04 9041051-04 9041051-04
9 9021010-04 9021010-04 9021010-04
10 9051142-02 9051142-01 9051142-01
11 9161076-02 9161079-03 9161079-03
12 9131111-01 9131111-01 9131111-01
13 6021032-01 6021032-01 6021032-01
14 9051001-09 9051001-09 9051001-09
15 9051153-06 9051153-06 9051153-06
16 9031046-24 9031046-24 9031046-24
17 9091086-02 9091086-02 9091086-02
18 9091086-03 9091086-03 9091086-03
19 9131026-02 9131026-02 9131026-02
20 3012747-01 N/A N/A
21 9031141-01 9031141-01 9031141-01 Plastic Nut Insert
Water Return Trough
Water Return Trough Screw
Valve Core
Valve Cap
Caplug
Curtain Stopper
Clamp
Water Pump Tube
Water Pump
Float Valve
Water Float Tube (26")
Snap Bushing
Evaporator-Half Cube
Evaporator Splash Curtain
Water Distribution Tube
Thumb Screw
Rubber Washer
High Pressure Control
Model Number
Model Number
Description
Left Hand Frame Panel
Right Hand Frame Panel
Evaporator-Full Cube
