ICE Series Service Parts Control Box
Item
No. ICE0250 ICE0400 ICE0406 ICE0500 ICE0606 Description
1 9101139-03 9101139-03 9101139-03 9101139-03 9101139-03 Purge Switch
2 9101195-01 9101195-01 9101195-01 9101195-01 9101195-01 ON-OFF-WASH Switch
3 9101083-01 9101083-01 9101083-01 9101083-01 9101083-01 Relay Socket
4 9101084-01 9101084-01 9101084-02 9101084-01 9101084-02 Relay
5 9101218-12 9101218-12 9101218-12 9101218-12 9101218-12 Water Pump Cord
6 9101002-07 9101002-03 9101002-04 9101002-03 9101002-04 Contactor
7 9181004-27 9181010-14 9181004-07 9181010-12 9181010-12 Compressor Start Relay
8 9181003-39 9181003-17 9181003-05 9181003-26 9181003-26 Start Capacitor
9 N/A N/A N/A 9181009-17 9181009-11 Run Capacitor
10 9101148-01 9101148-01 9101148-01 9101148-01 9101148-01 Timer
11 9041094-01 9041094-01 9041094-01 9041094-01 9041094-01 Low Pressure Timer Initiate
12 N/A N/A N/A 9041040-01 9041040-01 Pump Down Control
13 9101124-02 9101124-02 9101124-02 9101124-02 9101124-02 Bin Switch
Item
No. ICE0305 ICE0405 ICE0605
1 9101139-03 9101139-03 9101139-03
2 9101195-01 9101195-01 9101195-01
3 9101083-01 9101083-01 9101083-01
4 9101084-02 9101084-02 9101084-02
5 9101218-12 9101218-12 9101218-12
6 9101002-04 9101002-04 9101002-04
Water Pump Cord
Contactor
Model Number
Model Number
Description
Purge Switch
ON-OFF-WASH Switch
Relay Socket
Relay
Page 13
6 9101002-04 9101002-04 9101002-04
7 9181004-04 9181004-04 9181010-10
8 9181003-08 9181003-08 9181003-33
9 N/A N/A 9181009-11
10 9101148-01 9101148-01 9101148-01
11 9041094-01 9041094-01 9041094-01
12 N/A N/A 9041040-01
13 9101124-02 9101124-02 9101124-02
ICE0250 ICE0400 ICE0406 ICE0500 ICE0606 Description
9181121-11 9181086-11 9181086-12 9181085-12 9181112-11 Compressor
9181005-37 9181005-12 9181005-26 9181005-22 Internal Overload
9181004-27 9181010-14 9181004-07 9181010-12 9181010-12 Relay
9181003-39 9181003-17 9181003-05 9181003-26 9181003-26 Start Capacitor
N/A N/A N/A 9181009-17 9181009-11 Run Capacitor
ICE0305 ICE0405 ICE0605
9181088-11 9181088-11 9181112-12
9181005-26 9181005-26 Internal
9181004-04 9181004-04 9181010-10
9181003-08 9181003-08 9181003-33
N/A N/A 9181009-11
Relay
Start Capacitor
Run Capacitor
Low Pressure Timer Initiate
Pump Down Control
Bin Switch
Description
Compressor
Overload
Contactor
Compressor Start Relay
Start Capacitor
Run Capacitor
Timer
Model Number
Compressor Components
Model Number
Page 13
