IMC Networks IE-IMCV-T1-MUX/4 User Manual
Page 18
14
Console Screens
Configuration Using the Console Port
The following section describes configuration using the console screens. The Remote
module is only configured through the Host.
Login Screen
After running through an initial self test, the log-in screen is displayed (the diagnostic
information displayed below is for illustration purposes only and may differ from the
actual screen display):
The username is case sensitive with a maximum length of 16 characters. After a
username is entered, the system prompts the end-user for a password. Note that the
default user name and the default password is admin.
Password is case sensitive with a maximum length of 16 characters. After the system
validates the username and password, the Main Menu is displayed.
