MKIV Joystick Options
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Note See Footnote 1 1 1 N
1010848-NLA NLA - Clamp, Universal Swivel 1 1 2
12595X000 Handle, Lock, Chrome 1 1 3
15108X000 Locknut (1/4-20) 1 1 4
1044928 Joystick Tube with Plug Button Assembly 1 1 5
1027095 Plug Button, Black (7/8") 1 1 6
1025590 Joystick, Attendant Control (1552M) 1 1 7
1041544-NLA NLA - Joystick, Heavy Duty 1 1 8
1052719 Kit, Straight Joystick Tube with Hardware 1 1 9 A
1016401 Screw, Phillips Round Head (#10-32 x 3/8") 1 3 10
1027095 Plug Button, Black (7/8") 1 1 11
1044917 Hardware, Rear Cane Mount (1673/RCM) 1 1 12 B
1027095 Plug Button, Black (7/8") 1 1 13
1027274 Adjustment Lock Assemnbly, Black 1 1 14
1025245 Bracket, Upright, Black -Right 1 1 15
1044918 Tube, Joystick 1 1 16
1076284 Screw w/ Washer (#10 x 7/8") 2 1 17
1052309 Tube, Arm Mount with Plug Button, Black 1 1 18 C
1027095 Plug Button, Black (7/8") 1 1 19
1038638 Joystick, MKIV Dual/Compact 1 1 20
1108012 Hardware, Dual/Compact Joystick Clamp Mounting 1 1 21 D
1025048 Clamp 1 1 22
1021460 Screw, Socket Button Head (#10-32 x 5/16") 1 4 23
1025045 Clamp, Mounting 1 1 24
1027089 Screw, Socket Head (#10-24 x 1/2") 1 1 25
1026273 Spacer, Split (3/8" I.D.) 1 1 26
1020392 Chin Cup Assembly - 1826 1 1 27 E
1017545 Cup, Chin 1 1 28
1017612-NLA NLA - Screw, Adaptor 1 1 29 O
90032X000 Screw, Set Socket Cup Point (#8-32 x 1/4") 1 2 30
1091353-NLA NLA - Touchpad, Joystick Assembly 1 1 31
1092604 Kit, Straight Joystick Tube with Hardware 1 1 32 F
1027095 Plug Button, Black (7/8") 1 2 33
1052041 Screw, Phillips Pan Head (#4-40 x 3/8") 1 4 34
1049591 Hardware, Joystick Tube Mounting 1 1 35 G
1027267 Half Clamp, Threaded Holes 1 1 36
1027266 Half Clamp, Non-Threaded Holes 1 1 37
1027274 Adjustment Lock Assemnbly, Black 1 1 38
1049582-NLA NLA - Bracket, Joystick Mounting, Black 1 1 39
16690X004 Screw, Hex Head (1/4-20 x 1-1/8") 1 3 40
1093071 Clamp, Fixed Height Joystick Tube 1 1 41 H
1139422 Clamp, Height Adjustable Joystick Tube (ARM250) 1 1 42 I
1020818 Switch, Red Flex Ribbon (Tape) Reset 1 1 43 J
246
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 94-108
