Battery Box, Shrouds, Chargers and Cables
Item
Number
Part Number
Description
Note
Quantity Per
Package Assembly
1085685-NLA
NLA - Charger, Battery, 8 Amp. 115vac, Off Board,
Dual Mode, Square Plug w/ AC Power Line Cord,
Dynamic
1
1
14
D
1062556
Battery Charger, 8 Amp. 115vac (Off Board)
Single Mode Round Plug w/ AC Power Line Cord
and Square Plug Adapter Cable, CTE Corp.
1
1
14
B1,B2,
D
1089627
Cord, AC Power, 115VAC, 2 Prong Off-Board (11'
6" L)
1
1
15
1027965-NLA
NLA - Shroud, Center (14" W)
1
1
16
X
1027966-NLA
NLA - Shroud, Center (15" W)
1
1
16
X
1027967-NLA
NLA - Shroud, Center (16" W)
1
1
16
X
1027968-NLA
NLA - Shroud, Center (17" W)
1
1
16
X
1027969-NLA
NLA - Shroud, Center (18" W)
1
1
16
X
1027970-NLA
NLA - Shroud, Center (19" W)
1
1
16
X
1027971-NLA
NLA - Shroud, Center (20" W)
1
1
16
X
1027972-NLA
NLA - Shroud, Center (21" W)
1
1
16
X
1027973-NLA
NLA - Shroud, Center (22" W)
1
1
16
X
1028019-NLA
NLA - Decal, Center Shroud
1
1
17
1028362-NLA
NLA - Rivet, Snap
1
1
18
1010424
Cap, Anti-Wear
1
1
19
1022597
Screw, Phillips Pan Head Tap (#10-32 x 3/8")
1
2
20
1027263
Washer, Lock Tooth (3/16 x 3/8 x 1/32")
1
1
21
1030340-NLA
NLA - Shroud, Bottom, Mounting Bracket, Standard
Height
1
1
22
1034906-NLA
NLA - Shroud, Bottom, Mounting Bracket (2" Lower)
1
1
22
1030444-NLA
NLA - Decal, Pulley/ Clutch Shroud - Action Arrow
1
1
23
1028020
Decal, Pulley/ Clutch Shroud - Action Ranger X
1
1
23
1028021
Decal, Pulley/ Clutch Shroud - Action Ranger II
1
1
23
1022649
Guide, Cable, Battery Box
1
1
24
1029291-NLA
Holder, Fuse, 1559 Dual Mode Charger
1
1
25
1028809-NLA
NLA - Timer, 1559 Dual Mode Charger
1
1
26
1027962-NLA
NLA - Screw, Phillips Flat Head (10-32 x 1/2")
1
1
A,C
1030446-NLA
NLA - Bracket, Shroud Mounting
1
1
A,C
1053831
Cable, Adapter
1
1
27
See Chart
# 28 Pulley/Clutch Shroud - Grey
1
1
28
186
