A highly available and expandable, rack-dense, 2U dual-socket SMP server, for application
serving in Web environments
x3650 Specifications
Standard / maximum memory 8
2GB (2 x 1GB) / 48GB (BxX/BxY,
JxX/JxY, LxX/LxY, MxX/MxY
1GB (2 x 512MB) / 48GB (2xX/2xY,
4xX/4xY, 5xX/5xY, 7xX/7xY)
Standard memory type Fully buffered PC2-5300 (667MHz) DDR II ECC with Chipkill protection
Memory interleaving Yes (four-way using multiples of 4 DIMMs; two-way otherwise)
DIMM capacities supported 512MB, 1GB, 2GB, 4GB
# of DIMM sockets total / available 12 / 10
Online spare memory supported / # of
DIMM sockets reserved for sparing
Yes / 1 DIMM “rank” per memory branch (2 ranks total)
Memory mirroring supported / # of
DIMM sockets reserved for mirroring
Yes / 6
# of drive bays total / available
7 / 6 (x1X/x1Y, x2X/x2Y, x3X/x3Y,
x4X/x4Y, x5X/x5Y, x7X/x7Y, x9X/x9Y)
10 / 9 (xAX/xAY, xBX/xBY, xCX/xCY,
xDX/xDY)
# of HDD drive bays total / available
6 / 6 3.5-inch (x1X/x1Y, x2X/x2Y,
x3X/x3Y, x4X/x4Y, x5X/x5Y, x7X/x7Y,
x9X/x9Y)
8 / 8 2.5-inch (xAX/xAY, xBX/xBY,
BCX/BCY, xDX/xDY, xEX/xEY,
xGX/xGY)
# of 5.25" bays total / available 1 / 0 (CD-RW/DVD installed)
Maximum HDD capacity
3.5-inch SAS
1.8TB (6 x 300GB) hot-
swap SAS (without
internal backup drive);
1.2TB (4 x 300GB) hot-
swap SAS with internal
backup drive installed
(x1X/x1Y, L2X/L2Y,
x3X/x3Y, x4X/x4Y,
x7X/x7Y, x9X/x9Y)
2.5-inch SAS
1.17TB (8 x 146.8GB)
hot-swap SAS (with or
without internal backup
drive) (xAX/xAY, xBX/xBY,
xCX/xCY, xDX/xDY,
xEX/xEY, xGX/xGY,
xJX/xJY)
3.5-inch SATA
6.0TB (6 x 1TB) hot-swap
SATA (without internal
backup drive);
4.0TB (4 x 1TB) hot-swap
SATA with internal backup
drive installed (x1X/x1Y,
22X/22Y)
HDD capacities supported
3.5-inch SAS
73.4, 146.8, 300GB —
15K RPMs
2.5-inch SAS
73.4, 146.8GB — 10K
RPMs;
73.4GB — 15K RPMs
3.5-inch SATA
500, 750GB — 7.2K
RPMs
# of HDDs standard None
# of optical drives standard 1 CD-RW/DVD Combo (24X/10X/24X/8X, in dedicated 5.25" UltraBay)
# of diskette drives standard None (optional)
Internal backup drives supported
GoVault EZ Drive (USB 2.0 or SATA-attach), DDS-5 or VS160 (SCSI)—uses two 3.5”
bays
Disk drive technology Hot-swap SAS
Integrated disk controller Eight-port Adaptec 9580W SAS/SATA
# of disk drives supported per port 1
External disk drives supported
standard
Yes, via external 4-port SAS connector
Integrated RAID controller / cache ServeRAID-8k-l (32MB cache, 400MHz DDR2) standard—internal SAS
Optional RAID controllers supported
ServeRAID-8k (256MB, 400MHz DDR2)—internal SAS
ServeRAID-6M (128MB or 256MB)—external Ultra320 SCSI
MegaRAID 8480 (256MB)—external SAS/SATA
# of adapter slots total / available 4 / 4
# of PCI-E physical x8/electrical x8
slots (4GBps) 2 (standard)
One full-height/full-length (Slot 1); one full-height/half-length (Slot 2)
8 Maximum memory and disk capacity may require the replacement of standard components with the largest supported component
available.
Please see the Legal Information section for important notices and information.
