Icom IC-V85-T - Manual (Page 73)

60
13
CLONING
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Please refer to the HELP file that comes with CS-V85
CLONING SOFTWARE .
■
Cloning using a PC
PC
TRANSCEIVER
to USB port
to USB port
to RS-232C port
OPC-478
(RS-232C type)
OPC-478U
(USB type)
OPC-478UC
(USB type)
e Push [PTT] on the master
transceiver.
• “CL OU” appears in the master
transceiver’s display and S-
meter indicator shows that
data is being transferred to
the sub-transceiver.
• “CL In” appears automatically in the sub-transceiver’s display and
S-meter indicator shows that data is being received from the
master transceiver.
r When cloning is finished, turn power OFF, then ON again
to exit cloning mode.
NOTE: DO NOT push [PTT] on the sub-transceiver during
cloning. This will cause a cloning error.
DUP SCAN
PRIO SET H/M/L
OPT SKIP
BANK TONE T.SCAN P.BEEP
A B D C
CALL
ENT
MR CLR FUNC
PWR
9 8 7
4
1 2 3
5 6 0
