DTMF MEMORY
• DTMF memory indication
■
Transmitting a DTMF code
sequence
D
Using a DTMF memory channel
q Push
[FUNC]
, then push
[
OPT
]
(0) to enter
OPTION SET MODE
.
• Rotate
[VOL]
to select “dtm.OF,” if necessary.
w Push and hold
[
OPT
]
(0) for 1 sec. to select the DTMF mem-
ory.
e Rotate
[VOL]
to select the desired memory.
r Push
[MONI]
or
[PTT]
to exit the DTMF memory mode.
• Selected DTMF code sequence sounds when
[MONI]
is pushed.
t While pushing
[PTT]
, push
[MONI]
to transmit the selected
DTMF memory.
• After the DTMF code sequence is transmitted, the transceiver re-
turns to receive automatically.
Push
OPT
0
for 1 sec.
Push
FUNC
A
OPT
0
The DTMF memory consists of 5 pages that are 1st to 5th,
6th to 10th, 11th to 15th, 16th to 20th and 21st to 24th dig-
its.
Appears
Blinks
Appears
Appears
• 1st page indication
• 4th page indication
• 5th page indication
• 2nd page indication
• 3rd page indication
