Intel D915GVWB - Manual (Page 2)

FEA
TURES AND BENEFITS
Intel ® Desktop Board D915GVWB
9 9
5
PS/2
USB AUDIO USB
LAN
SERIAL
PARALLEL
8
6
4
9
9
1 Support for the Intel ® Pentium ® 4 and Intel ® Celeron ® D processor: Supports
Intel ® processors featuring the 800- or 533-MHz system bus via the LGA775
socket. Supports boxed Intel processors with packaging designated by 04A
or 04B Platform Compatibility Guide.
2 Intel ® 915GV Express Chipset featuring Intel ® Graphics Media Accelerator 900:
Low-cost high-performance integrated graphics solution.
3 Dual-Channel DDR 400/333 SDRAM support: Four DIMM sockets designed
to support up to 4 GB
1 of SDRAM memory.
4 Four Serial ATA150 ports: Facilitates high-speed storage transfers at up to
1.5 GB/s per port, allows easy hard drive upgrades and expansion for new
SATA optical drives.
5 Integrated Intel ® PRO 10/100 LAN (optional): Onboard 10/100-Mbps Ethernet
LAN connectivity.
6 Intel ® High Definition Audio: Flexible six-channel audio with jack sensing.
This new standard in PC audio provides an outstanding user experience
for movies, music, and games with higher bit rate processing (24-bit), flexible
5.1 audio capability, and improved jack sensing.
7 Two PCI connectors: Expansion slots for custom system configurations and
future add-in card upgrades.
8 One PCI Express* x1 connector: With up to a 500 MB/s concurrent data
transfer bandwidth, more than doubles the I/O bandwidth of traditional
PCI architecture.
9 Eight Hi-Speed USB 2.0 ports: Four back-panel ports and an additional
four front-panel USB ports via two internal headers.
10 Intel ® Precision Cooling Technology: Advanced management ASIC supports
temperature-based fan control. System fan noise may be reduced by controlled
chassis and processor fans operating at the minimum necessary speeds.
11 Instantly-Available PC (suspend-to-RAM): Enables advanced power savings
(not pictured).
