Impex ADI-5100-I User Manual
Page 12
©IMPEX INC. www.impex-fitness.com
11
2
Rear Stabilizer
1
3
Front Post
1
4 Seat
Bracket
2
5
Leg Developer
1
6
Backrest Incline Support
1
7
Backrest Support
2
8
Backrest Board
1
9
Seat Pad
1
10
Seat Lock Pin
1
11
Bracket
4” x 2”
1
12
Bracket
6 ¼” x 4”
1
13
Seat Incline Support Frame
2
14
Foam Tube
15 ¾”
2
15
Long Foam Tube
17 3/8”
1
16
End Cap
1 5/8” x 2 3/8”
2
17
End Cap
1” x 1”
8
18
End Cap
Ø 1”
2
19
Foam Roll End Cap
6
20
Bushing
Ø 1 ½” x 1”
2
21
Leg Developer Bushing
Ø 2 3/8” x 7/8”
2
22
Foam Roll
6
23
Base End Cap
3
24
Rubber Bumper
Ø ¾” x 1 1/8”
2
25
Olympic Sleeve
1
26 Roller
Wheel
2
27
Rubber Bumper
1 5/8” x 1 5/8”
1
28
Seat Incline Frame
1
29
Leg Developer Axle
1
30 Spring
1
31
U-shaped Lock Pin
1
32
Spring Clip
Ø 1 7/8”
1
33
Spring Clip
Ø 7/8”
1
34
Allen Bolt
M10 x 8 7/8”
2
35
Allen Bolt
M10 x 6 ¾”
1
36
Allen Bolt
M10 x 4 ¾”
5
37
Allen Bolt
M10 x 2 ¾”
4
38
Allen Bolt
M10 x 5/8”
2
39
Allen Bolt
M8 x 1 5/8”
10
40
Allen Bolt
M6 x ½”
1
41 Washer
Ø
¾”
24
42 Washer
Ø
5/8”
12
43 Spacer
Ø
½”
1
44 Aircraft
Nut
M10
10
45 Aircraft
Nut
M8
2
46 Cover
Cap
M10
10
47 Cover
Cap
M8
2
Allen Wrench (Tool)
6#
2
Allen Wrench (Tool)
5#
1
Allen Wrench (Tool)
4#
1
