Specification Update 9
Intel
®
80219 General Purpose PCI Processor
Summary Table of Changes
Non-Core Errata
No.
Steppings
Page Status Errata
A-0
1 X 20 NoFix
The ATU Returns Invalid Data for the DWORD that Target Aborted from the MCU when
Using 32-Bit Memory, ECC Enabled and in PCI Mode
2 X 20 NoFix PBI Issue When Using 16-bit PBI Transactions in PCI Mode
3 X 21 NoFix MCU Pointers are Incorrect following a Restoration from a Power Fail
4 X 21 NoFix
PMU Does Not Account for when the Arbiter Deasserts GNT# One Cycle before
FRAME#
5 X 21 NoFix Lost Data During Bursts of Large Number of Partials with 32-bit ECC Memory
6 X 22 NoFix
The MTTR1 (Core Multi-Transaction Timer) is not operating due to improper behavior of
the core internal bus request signal (REQ#)
7 X 22 NoFix The MCU supports a page size of 2 Kbytes for 64-bit mode
8 X 23 NoFix Vih Minimum Input High Voltage (Vih) level for the PCI pins
