Specification
Power requirement
47.0W
Power supply
120V AC 60Hz
Mass
4.3kg
External dimension
Width 435 x Height 73 x Depth 346mm
(17-1/8˝ Ч 2-7/8˝ Ч 13-5/8˝)
Signal system
Standard NTSC Color TV system
Laser
Semiconductor laser
Wavelength: 405nm/650nm/780nm
VIDEO output
1.0Vp-p (75 W), Sync signal negative,
Pin jack x 1 system
S VIDEO output
(Y) 1.0Vp-p (75 W), Sync signal negative,
(C) 0.286Vp-p (75 W), 1 at rear
Mini DIN4 Pin x 1 system
Component output (Y, P
B
, P
R
)
Y output (green), 1.0Vp-p (75 W),
Pin jack x 1 system
P
B
, P
R
output (blue, red), 0.7Vp-p (75 W),
Pin jack x 1 system each
Analog audio output
2.0V (rms), 2.2k W or below, pin jack
(L, R) x 1 system
2.0V (rms), 2.2k
W or below, pin jack x 6
Digital audio output (OPTICAL/COAXIAL jack)
Optical connector x 1 system
Coaxial pin jack x 1 system, 0.5Vp-p (75
W)
ETHERNET port
100BASE-TX/10BASE-T x 1
EXTENSION port
2 systems
RS-C connector
DSUB 9 pin
HDMI output
19 pin, Type A connector
Remote control
Wireless remote control (RC-716DV)
Operating conditions
Temperature: 41°F ~ 95°F (5°C ~ 35°C)
Position: Horizontal
Clock accuracy
Quartz (monthly deviation: approximately ±30 seconds)
• Designs and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
• The illustrations and screens described in this manual may be exaggerated or simplified for easy recognition and may be slightly
different from the actual unit.
