GA-945P-DS3/S3 Motherboard - 18 -
English
1-7 Connectors Introduction
In addition to the default speakers settings, the ~ audio jacks can be reconfigured to
perform different functions via the audio software. Only microphones still MUST be connected
to the default Mic In jack ( ) . Please refer to the 2-/4-/6-/8- channel audio setup steps for
detailed software configuration information.
1) ATX_12V
2) ATX (Power Connector)
3) CPU_FAN
4) SYS_FAN
5) PWR_FAN
6) NB_FAN
7) FDD
8) IDE1
9) SATAII0/1/2/3
10) PWR_LED
11) F_PANEL
12) F_AUDIO
13) CD_IN
14) SPDIF_IO
15) F_USB1/F_USB2
16) CI
17) CLR_CMOS
18) BATTERY
3 1
15
2
10 14 4
17
13 11
9
18
12
7
8
16
5
6
