STEP4.3: Create the tables in the database
To continue with the next steps
– you must have installed a database management system (i.e. DB2).
– you must have a JDBC Driver for it (i.e. db2java.zip in \java\).
– you must be able to connect to the database (userid/password)
Make sure the JDBC driver is in the CLASSPATH. You may have to edit
the create.bat/create.cmd/create.sh batch files as well as the
run.bat/run.cmd/run.sh batch files and add the JDBC Driver Archive to
the classpath:
set CLASSPATH=.;xerces.jar;\java\ db2java.zip;
%CLASSPATH%
Also the path must setup to contain the DB2 libraries.
Start the "
Create DB2 Tables " utility (create.bat/create.sh or START -
Programs - VSAM Redirector - Create DB2 Tables ).
The tool prompts you for the following:
– XML Filename: enter the name of the XML File you exported in the last
step (i.e. ffstores.xml )
– DB url: enter a JDBC URL for your database, i.e. jdbc:db2:sample
– DB user: enter a user id you use for accessing the database
– DB password: enter the users password
– DB table name: Enter the name of the data table, i.e. FFSTORES . This
table will later contain the VSAM data.
– Map table name: Enter the name of the table that contains the mapping
information, i.e. FFSTORES_MAP. You can use the same map table for
several clusters.
– Map name: Enter the name of the map, i.e. FFSTORES. This name is
independent from the map defined with the VSE Navigator.
– DB system: Enter 1 for DB/2 , 2 for Oracle.
– The tool now imports the XML file and tries to connect to the database.
– Next, the map info table is created (FFSTORES_MAP). Enter "Yes" to
continue.
– Then, the data table is created (FFSTORES). Enter "Yes" to continue.
– Cluster Type: Enter 1 ( KSDS without AIX ).
– Primary key field: Enter the name of the key field: STOREID . Press
enter to create the table and indexes.
Redirect a VSAM file to DB2
