Mapping of FFSTORES.DEMO.CLUSTER:
Field name Type Offset
Length
STOREID STRING 0 6
STORENAME STRING 6 25
LOCSTREET STRING 31 25
LOCCITY STRING 56 25
LOCZIP STRING 81 10
LOCCOUNTRY STRING 91 25
LOCREP STRING 116 20
STOREN1 UNSIGNED 136 4
STOREN2 UNSIGNED 140 4
LDATE STRING 144 10
WEBPIC1 STRING 154 20
WEBPIC2 STRING 174 20
ACODE STRING 194 10
To verify the mapping, use the VSE Navigator to display the VSAM data.
Right click on the map, choose "
Display VSAM Data ". On the "Display
Filter" dialog box, press "OK" to display all records (no filter).
STEP4.2: Export the mapping to a XML File
The VSAM Redirector "Create DB2 Tables" tool reads the mapping from a
XML file.
Right click on the map and choose "
Export map to XML ". Enter a filename
(e.g. ffstores.xml ). You will need this file in the next step.
Redirect a VSAM file to DB2
