32
NS-L47Q09-10A Insignia 47" LCD TV
www.insigniaproducts.com
Specifications
Design and specifications are subject to change
without notice.
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the
user’s authority to operate this equipment.
Cables
Connections to this device must be made with shielded cables
with metallic RF/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Canadian notice
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
“Standard Television Receiving Apparatus-Appareil de reception
télévision ordinaire, Canada BETS-7 / NTMR-7”.
Dolby License Notice and Trademark Acknoledgement
Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks of Dolby Laboratories.
HDMI
HDMI, the HDMI logo, and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC.
SRS TruSurround HD
is a trakemark of SRS Labs, Inc.
TruSurround HD technology is incorporated under license from
SRS Labs, Inc.
Analog standard NTSC
Digital standard ATSC, 8-VSB, Clear-QAM
Screen 47”
Channel coverage VHF: 2-13
UHF: 14-69
CATV: Mid band - A-8 ~ A-1, A ~ I
Super band - J ~ W
Hyper band - AA ~ ZZ, AAA, BBB
Ultra band - 65 ~ 94, 100 ~ 135
Power source AC 120 V ~ 60 Hz
Power consumption 260 Wwith TV on
<1 W in standby mode
Audio power 10 W + 10 W internal speaker
S-Video input (2) Y: 1 V (p-p), 75 ohm, negative sync
C: 0.286 V (p-p) (burst signal), 75 ohm
Video/audio input (2) Video: 1 V (p-p), 75 ohm, negative sync
Audio: 300 mV (rms)
Component input (2) Y: 1 V (p-p), 75 ohm, including sync
Pr/Cr: ±0.35 V (p-p), 75 ohm
Pb/Cb: ±0.35 V (p-p), 75 ohm
Audio: 300 mV (rms)
Suggested resolutions: 1080P, 1080i, 720p, 480p,
480i
HDMI input (4) 4 HDMI input jacks
HDCP compliant
E-EDID compliant
Suggested scan rates: 1080p, 1080i, 720p, 480p,
480i
VGA input E-EDID compliant
Suggested scan rates: 640x480/60 Hz,
800x600/60 Hz, 1024x768/60 Hz,
1920x1080/60 Hz
Audio input: Headphone mini-jack for stereo
Accessories Remote control and batteries (2 AAA)
AC power cord
Component cable
User guide
Quick Setup Guide
