0 pin and signal descriptions, 1 pin locations, 1 1.8” pin locations – Intel SSDSA1MH080G1 User Manual
Page 16: Figure 6. layout of signal and power segment pins
Intel
®
X18-M/X25-M SATA SSD
Intel
®
X18-M/X25-M SATA Solid State Drive
Product Manual
May 2009
16
Order Number: 319765-008US
Intel
®
X18-M/X25-M SATA SSD
5.0
Pin and Signal Descriptions
This section identifies the pin locations and signal descriptions of the Intel X18-M/
X25-M SATA SSDs.
5.1
Pin Locations
5.1.1
1.8” Pin Locations
Figure 6.
Layout of Signal and Power Segment Pins
Signal Segment S1
Power Segment P1
