ADI-10242 PARTS LIST
PART NO. DESCRIPTION SIZE QUANTITY
1 Upright Beam 2
2 Base Frame 2
3 Cross Brace 1
4 Left Rear Support 1
5 Right Rear Support 1
6 Safety Catch 2
7 Bar Catch 2
8 Weight Plate Storage Post 2
9 Bracket 5 ½” x 2” 2
10 Bracket 5 1/8”x 2 ¾” 2
11 Lock Pin Ø ½” x 5 ¼” 4
12 Sleeve Ø 4 ½” x 1 1/8” 8
13 Upright Beam Top Cap 2
14 End Cap Ø 1” 2
15 Olympic Sleeve Ø 2” x ¼” 2
16 Rubber Bumper 1 ½” x 5 ¾” 2
17 Rubber Bumper 1 ½” x 3” 2
18 Cover Cap M10 16
19 Spring Clip Ø 2” 2
20 Spring Clip Ø 7/8” 2
21 Allen Bolt M10 x 4 ¾” 4
22 Allen Bolt M10 x 4 ½” 4
23 Allen Bolt M10 x 3” 8
24 Allen Bolt M10 x ¾” 6
25 Washer Ø ¾” 38
26 Aircraft Nut M10 16
Allen Wrench (Tool) 6# 1
Allen Wrench (Tool) 4# 1
