The Signal Connector
A signal connector is present on this pod, marked as ST4.
Pin Signal Description
1
GND
Ground
2
BPEXT External Breakpoint
3
RESO
Reset Output
4
TRES
Target Reset
5
AUX0
Auxilliary Signal Input
6
AUX1
Auxilliary Signal Input
7
AUX2
Auxilliary Signal Input
8
AUX3
Auxilliary Signal Input
ST4 Connector signals
Target Adapters
iSYSTEM offers various adapter solutions for this POD. Please refer to the adapter documentation for more
details.
