2 Installation
11
MT5600BR-V92 User Guide
Switch Function
Position
Effect
#5
Answer/Originate*
UP*
Answer Mode
(Async/Sync/Leased Line)
DOWN
Originate Mode
#6
Max-Throughput Enabled*
UP*
Modem set-up to
(Async/Dial-Up/Leased)
DOWN
operate at highest
efficiency level
#6
Slave Clock Disabled*
UP*
Slave Clocking OFF
(Sync/Dial-Up/Leased)
DOWN
Slave Clocking ON
#7
RTS/Normal/Forced*
UP
RTS dependent on interface
(Sync/Async/Dial/Leased)
DOWN*
RTS forced ON
#8
Command Mode Enabled*
UP
Disable Command Mode
(Sync/AsyncDial/Leased)
DOWN*
Enabled Command Mode
#9
No affect
#10
Dial-Up*/Leased-Line
UP*
Dial-Up Operation
DOWN
Lease Line Operation
#11
No affect in async
#11
Internal*/External Clocking
UP
External Clock
(Synchronous)
DOWN*
Internal Clock
#12
Sync/Async Mode*
UP
Sync Operation
DOWN*
Async Operation
Dip Switch Settings #13 - 16
Switch Position
Effect
13/14
UP/UP*
V.92 Operation (Default)
13/14
DOWN/UP
V.34 Operation
13/14
UP/DOWN
V.32b Operation
13/14
DOWN/DOWN
V.22b Operation
#15
UP*
CD/DSR from Interface
#15
DOWN
CD/DSR Forced On
#16
UP
2-WireOperation
#16
DOWN
4-Wire Operation
* Factory default setting
