Srs air bags – Mazda 2006 5 User Manual
Page 56
Black plate (56,1)
qFront Air Bag System Components
(8)
(5)
(7)
(6)
(5)
(4)
(3)
(2)
(1)
(9)
(10)
(1) Front dual stage inflators and air bags
(2) Front air bag sensor
(3) Front passenger air bag deactivation indicator light (page 2-46)
(4) Crash sensors and diagnostic module (SAS unit)
(5) Front seat belt pretensioner and load limiting systems (page 2-19)
(6) Front passenger seat weight sensors (page 2-46)
(7) Seat weight sensor control module
(8) Driver and front passenger seat belt buckle switches (page 2-46)
(9) Driver seat slide position sensor (page 2-46)
(10) Front seats
2-44
Essential Safety Equipment
SRS Air Bags
Mazda5_8U38-EA-05D_Edition1 Page56
Monday, March 28 2005 1:58 PM
Form No.8U38-EA-05D
