Page 136
Black plate (136,1)
CAUTION
Driving with an overheated engine can
cause serious engine damage (page
7-13).
qFuel Gauge
The fuel gauge shows approximately how
much fuel is in the tank. We recommend
keeping the tank over 1/4 full. When the
low fuel warning light illuminates or
when the needle is near E, refuel as soon
as possible.
Low fuel
warning light
NOTE
The direction of the arrow (
) shown
next to the low fuel warning light
indicates that the fuel-filler lid is on the
right side of the vehicle.
qDashboard Illumination
When the exterior lights are on, rotate the
knob to adjust the brightness of the
dashboard lights.
Dim
Bright
5-30
Driving Your Mazda
Instrument Cluster and Indicators
Mazda5_8U38-EA-05D_Edition1 Page136
Monday, March 28 2005 2:9 PM
Form No.8U38-EA-05D
