42" PLASMA DISPLAY
Connecting to a Second PDP or Monitor
You can send output from the PDP to a second PDP or other video device by connecting a composite
video cable from the TV1 and Video 1 outputs on the rear of the PDP.
To connect to a second PDP follow these steps:
1. Connect the Video Out output of the PDP to the video input of the secondary device using a
composite video cable. Connect the audio (white and red) to Audio Out (L, R) connectors.
2. Turn on the PDP and the second PDP or monitor.
3. Set the second PDP to receive composite video input. Refer to the user manual of the second PDP
or monitor for further details.
NOTE:
•
The output displayed on a second PDP is the same as the current input of the PDP.
• You can only connect to a second PDP using the Video Out/Audio Out connectors and composite
cable.
