4G9 ENGINE (E–W) – Specifications
11A-1-1
1. SPECIFICATIONS
SERVICE SPECIFICATIONS
Items Standard value Limit
Timing belt
Auto-tensioner rod protrusion amount (When removed from engine)
mm 11 –
Auto-tensioner rod stroke mm Within 1 –
Auto-tensioner rod protrusion amount (When checking with installed
on engine) mm 3.8 – 4.5 –
Rocker arms and camshaft
Camshaft cam
height mm
4G92–SOHC* 1 Intake 37.34 36.84
height mm
G S C
Exhaust 36.79 36.29
4G92–SOHC* 2 Intake 37.78 37.28
G S C
Exhaust 37.83 37.33
4G92–SOHC* 3 Intake 36.92 36.42
G S C
Exhaust 36.70 36.65
4G93–SOHC* 4 Intake 37.53 37.03
G S C
Exhaust 37.64 37.14
4G93–SOHC* 5 Intake 37.11 36.61
G S C
Exhaust 37.15 36.65
4G94–SOHC
Intake 37.91 37.41
S C
Exhaust 37.70 37.20
4G93–DOHC
Intake 35.31 34.81
G C
Exhaust 35.20 34.70
4G93–DOHC–GDI
Intake 35.49 34.99
4G93 DOHC GDI
Exhaust 34.73 34.23
4G94–DOHC–GDI
Intake 35.49 34.99
4G94 DOHC GDI
Exhaust 34.91 34.41
Valve clearance mm Intake 0.09 –
Exhaust 0.20 –
Camshaft journal O.D. mm SOHC 26.0 –
DOHC 45.0 –
Rocker cover and camshaft (MIVEC)
Camshaft height mm Intake A 36.41 36.91
Intake B 33.58 33.08
Exhaust A 35.83 35.33
Exhaust B 34.24 33.74
Valve clearance (cold engine) mm Intake 0.1 –
Exhaust 0.2 –
* 1 : LANCER for Europe and CARISMA for Europe
* 2 : LANCER for general export and CARISMA for 6B model
* 3 : LANCER for Europe (from 2001 model) and CARISMA for Europe (from 2001 model)
* 4 : Except for Europe
* 5 : For Europe
