S12
TYPE
Compact sub-bass system
FREQUENCY RESPONSE (1)
52Hz-150Hz ± 3dB
LOW FREQUENCY LIMIT
43Hz (-10dB)
DRIVER
1 x 12" (300mm)/3" (75mm) voice coil LF driver
RATED POWER (2)
400W AES, 1600W peak
RECOMMENDED AMPLIFIER
400-800W into 4 ohms
SENSITIVITY (3)
96dB
MAXIMUM SPL (4)
120dB continuous, 126dB peak
IMPEDANCE
8 ohms nominal
CROSSOVER
120Hz, switchable passive/active
ENCLOSURE
55 litre (1.94 cu foot) vented,
multi-laminate birch ply
FINISH
Textured black paint
PROTECTIVE GRILLE
Black perforated steel
CONNECTORS
2 x Neutrik Speakon NL4
FITTINGS
1 x top hat fitting
DIMENSIONS
(W) 398mm x (H) 571mm x (D) 364mm
(W) 15.6ins x (H) 22.5ins x (D) 14.3ins
WEIGHT
20kg (44lbs)
SHIPPING DIMENSIONS
(W) 480mm x (H) 510mm x (D) 660mm
(W) 19ins x (H) 20ins x (D) 26ins
SHIPPING WEIGHT
28kg (61.5lbs)
Notes
1. Measured on-axis in half space at 2 metres, then referred to 1 metre.
2. AES Standard ANSI S4.26-1984.
3. Measured in half space conditions at 2 metres with 1 watt input, using band limited pink noise,
then referred to 1 metre.
4. Measured in half space conditions at 2 metres using band limited pink noise, then
referred to 1 metre.
Due to our policy of continuous improvement all specifications are subject
to change without notice.
Martin Audio – Blackline F8, F10, S12
E
NGLISH
13
All material © 2007. Martin Audio Ltd. Subject to change without notice.
