10 TECHNICAL

SPECIFICATIONS

F8

TYPE

Ultra-compact, two way passive

FREQUENCY RESPONSE (1)

70Hz-20kHz ± 3dB

LOW FREQUENCY LIMIT

55Hz (-10dB)

DRIVERS

1 x 8" (200mm)/2"(50mm) voice coil LF driver

1 x 1" (25mm) exit HF compression driver

RATED POWER (2)

150W AES, 600W peak

RECOMMENDED AMPLIFIER

200-600W into 4 ohms

SENSITIVITY (3)

93dB

MAXIMUM SPL (4)

113dB continuous, 119dB peak

IMPEDANCE

8 ohms nominal

DISPERSION (-6DB)

90˚ H x 50˚ V

CROSSOVER

2.5kHz passive

ENCLOSURE

14.8 litre (0.5 cu foot) vented, multi-

laminate birch ply

FINISH

Textured black paint

PROTECTIVE GRILLE

Black perforated steel

CONNECTORS

2 x Neutrik Speakon NL4

FITTINGS

10 x M8 threaded inserts

4 x M6 inserts for HTKM10 wall bracket

1 x top hat fitting

DIMENSIONS

(W) 299mm x (H) 435mm x (D) 269mm

(W) 11.8ins x (H) 17.1ins x (D) 10.6ins

WEIGHT

12kg (26lbs)

SHIPPING DIMENSIONS

(W) 330mm x (H) 600mm x (D) 620mm

(W) 13ins x (H) 23.7ins x (D) 24.5ins

SHIPPING WEIGHT

27.5kg (60.5lbs) (packed in pairs)

Martin Audio – Blackline F8, F10, S12

E

NGLISH

11

All material © 2007. Martin Audio Ltd. Subject to change without notice.
