F10
TYPE Compact, two way passive
FREQUENCY RESPONSE (1) 65Hz-20kHz ± 3dB
LOW FREQUENCY LIMIT 56Hz (-10dB)
DRIVERS 1 x 10" (250mm)/2 1/2"(63mm) voice coil LF driver
1 x 1" (25mm) exit HF compression driver
RATED POWER (2) 300W AES, 1200W peak
RECOMMENDED AMPLIFIER 400-650W into 4 ohms
SENSITIVITY (3) 96dB
MAXIMUM SPL (4) 119dB continuous, 125dB peak
IMPEDANCE 8 ohms nominal
DISPERSION (-6DB) 90˚ H x 50˚ V
CROSSOVER 2kHz passive
ENCLOSURE 23 litre (0.8 cu foot) vented,
multi-laminate birch ply
FINISH Textured black paint
PROTECTIVE GRILLE Black perforated steel
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS 10 x M8 threaded inserts
4 x M8 inserts for HTKM20 wall bracket
1 x top hat fitting
DIMENSIONS (W) 351mm x (H) 500mm x (D) 317mm
(W) 13.8ins x (H) 19.7ins x (D) 12.5ins
WEIGHT 17kg (37lbs)
SHIPPING DIMENSIONS (W) 430mm x (H) 470mm x (D) 580mm
(W) 17ins x (H) 18.5ins x (D) 23ins
SHIPPING WEIGHT 20kg (44lbs)
