Metrologic Instruments Solaris MS7820 User Manual
Page 29
25
I
NSTALLATION
W
ALL
M
OUNT
S
TAND
I
NSTALLATION
5. Secure the wall mounting plate to the wall location designated in Step 1 and
assemble the remaining parts as shown in Figure 23.
Figure 23. Scanner Mounting Plate Assembly
6. Slide the scanner onto the mounting plate until the plate is fully seated into
the scanner.
Figure 24. Slide mounting plate into scanner.
