1.4 FRONT PANEL 1.4 FRONT PANEL
Continued Continued … …
6
1) “HDD Cartridge Lock” :
Lock / Unlock the cartridge of the HDD.
2) “USB” :
Support firmware update and files backup.
3) “LED LIGHT” :
HDD: HDD is reading or recording
HDD Full: HDD is full.
ALARM: Once the alarm is triggered
TIMER: When timer recording is turned on
PLAY: Under playing status
REC: Under recording status
4) “MENU” :
Press “MENU” button to enter main menu.
5) “ENTER” / “SET” :
Press “ENTER” button to confirm.
Press “SET” to change channel display position.
Press “
◄►
“ to select the channel which you like to change,
Press “ ” or “ ” select the channel which You would like to show.
Press “ENTER” button to confirm.
6) “SEARCH ” :
Press “SEARCH” button to enter the search mode.
7) “SLOW ” :
Under playback mode, press “SLOW“ button to show slow playback.
4CH
