APPENDIX #3 APPENDIX #3
APPENDIX #3 APPENDIX #3 – – RS RS - - 232 Protocol 232 Protocol
53
G 0x47 KEY_CH16
F 0x46 KEY_CH15 K 0x4B KEY_KEY LOCK
E 0x45 KEY_CH14 W 0x57 KEY_POWER
D 0x44 KEY_CH13 R 0x52 KEY_RIGHT
C 0x43 KEY_CH12 N 0x4E KEY_DOWN
B 0x42 KEY_CH11 P 0x50 KEY_PLAY
A 0x41 KEY_CH10 U 0x55 KEY_UP
9 0x39 KEY_CH9 L 0x4C KEY_LEFT
8 0x38 KEY_CH8 r 0x72 KEY_REC
7 0x37 KEY_CH7 S 0x53 KEY_SLOW
6 0x36 KEY_CH6 c 0x63 KEY_16 CUT
5 0x35 KEY_CH5 b 0x62 KEY_9 CUT
4 0x34 KEY_CH4 z 0x5A KEY_ZOOM
3 0x33 KEY_CH3 a 0x61 KEY_4 CUT
2 0x32 KEY_CH2 ENTER 0x0D KEY_ENTER
1 0x31 KEY_CH1 M 0x4D KEY_MENU
ASCCI CODE FUNCTION ASCII CODE FUNCTION
1) Use PC keyboard to simulate DVR keypad.
2) Data: REMOTE PROTOCOL use 8 bit data, 1 start bit, 1 stop bit.
