iv
T
ABLE OF
C
ONTENTS
IR Activation ....................................................................................................... 25
Applications and Protocols ................................................................................. 26
Troubleshooting Guide ....................................................................................... 27
RS232 Demonstration Program ......................................................................... 30
Design Specifications
Operational..................................................................................................... 31
Mechanical ..................................................................................................... 32
Electrical......................................................................................................... 32
Environmental ................................................................................................ 32
Default Settings .................................................................................................. 33
Scanner and Cable Terminations
Scanner Pinout Connections .......................................................................... 38
Cable Connector Configurations .................................................................... 40
Limited Warranty ................................................................................................ 42
Laser and Product Safety................................................................................... 43
Patents ............................................................................................................... 45
Index................................................................................................................... 46
