SSEMBLING THE

TAND

Wall Mount, Option 1:

For Kit #46-46433 or #46-46508

Step 1
Drill two #39 pilot holes 3.00” apart.

Step 2
Attach the Wall Mount Hanger to the wall
with the two #8 wood screws provided.

Wall Mount, Option 2:

Kit #46-46508

Step 1
Attach the Wall Mount Base to the Wall
Mount Hanger with the two 4.8 x 13 mm
self-tapping screws.

Step 2
Remove one side of the protective
backing from the double-sided adhesive
tape.

Step 3
Attach the tape to the back of the Wall
Mount Hanger as shown.

Step 4
Remove the protective backing from the
double-sided adhesive tape and apply
hook to the wall.

Figure 26.

Figure 27.

Figure 28.
