Adjustment Settings for Operators
247
9
Process
❖ Select Test Pattern
❖ 3–740–001 : Select Test Pattern
• Trim Pattern
❖ Reset to Defaults
❖ 3–740–002 : Reset to Defaults
Peripherals
❖ Staple Position Adjustment
❖ 6-700-001 : A3-Lengthwise
• Max: 2 mm
• Min: -2 mm
• Step: 0.5 mm
• Initial value: 0 mm
❖ 6-700-002 : B4 SEF
• Max: 2 mm
• Min: -2 mm
• Step: 0.5 mm
• Initial value: 0 mm
❖ 6-700-003 : A4 SEF
• Max: 2 mm
• Min: -2 mm
• Step: 0.5 mm
• Initial value: 0 mm
❖ 6-700-004 : A4 LEF
• Max: 2 mm
• Min: -2 mm
• Step: 0.1 mm
• Initial value: 0 mm
