TP6000 USER’S MANUAL 4 - 7
This program controls software gating of data read from each MSR track and
the way that the data is sent from the reader to the system, including the coding
method against language systems, data transmission speed, delivery and selection on
the leading/ending code of each track.
This program also controls the beep generated when the touch panel is
touched, the detail in right button click emulation, and also provides touch panel re-
calibration.
This program can also be used to define the power switch to be on only or
on/off, the delay time before software power off and whether a UPS battery is
activated in the power control system.
RS232 TOUCH MONITOR MOUSE
If the product model purchased is TP6XXXR, the touch panel uses an RS232
interface controller. The “Touch Panel Manager” of the above “Posiflex Touch
Terminal Manager” should be disregarded and a separate software called Monitor
Mouse should be used. In these models, the COM2 connector on system revision A or
the COM4 connector (in form of RJ45 jack) on system revision since B will be either
covered or plugged to prohibit any use of this port other than the connected RS232
touch controller. Removal of this cover/plug will void the product warranty!!
In principle, the driver is installed with the systems equipped with the RS232
touch controller. However, if a re-installation is required, please select “SmartSet
Serial Controller on COM2” for system revision A or “SmartSet Serial controller on
COM4” for system revision since B as the controller type during the installation
process.
Once the RS232 touch controller driver is installed, the user can utilize it to
calibrate the touch screen, define mouse button emulation modes, enable right button
emulation or define the click sound’s tone and duration. Please click “Start”,
“Setting”, “Control Panel” and “Elo Touchscreen” to engage this utility. However,
with this touch controller driver, certain display mode like full screen display of
Windows DOS box should be avoided.
If, for any reason, the user wants to remove the driver for the RS232 touch
controller, please select “Monitor Mouse for Windows 95” in the program list for
removal.
