TP6000 USER’S MANUAL 3 - 3
INSTALLING UPS BATTERY
Place the optional UPS battery in the battery compartment (shown top left).
Screw on the battery cover and route the battery cable through the base. Please enable
the UPS features in the software settings before use.
ROUTING THE CABLES
Place all required cables into the cable passage.
Insert one end of the cable passage cover under the
battery cover and replace the two screws. Be sure not
to damage any of the cables during this operation.
Now, turn the adjustable stand
assembly back to normal orientation and arrange all cables so
that they will be easily connected after the terminal is mounted
to the base.
UPS Battery
Removed
Battery
Cover
