TP6000 USER’S MANUAL 3 - 5
toward the upper round part of the hole and make sure that all pegs have been
properly seated. Then slide the main unit down to move the pegs into the narrow
section of the slot until the rear latch clicks. Note that all the cables come out of the
stand from the lower edge and won’t get trapped by this mounting operation. If later
on you want to remove the main unit from the stand, you’ll have to press down the
lock/release button on back of the stand when lifting the main unit.
OPENING CABLE COVER
Insert the tip of the latchkey into a latch hole on one side near bottom of the
main unit. Turn this key counterclockwise to the end. Do the same on the opposite
side. Be sure to take the key out of the hole.
Then push the lock/release lever on the base backward to adjust the stand to
the most horizontal position for ease of operation. Open the cable cover by pulling at
the removal hole.
Turn Counterclockwise
Then Take Out The
Latchkey
Pull The Removal Hole
Away from the machine.
