Getting Star
ted
Battery Drop-In Charging Tray
The Drop-In Charging Tray can be placed on
any flat surface and provides drop-in charging
convenience.
• Connect Plug-in Charger and Drop-In Charging
Tray by inserting the pin into the rear of Drop-
In charging tray, insert pin as far as possible,
then stop.
• To charge the battery, place the radio into
Drop-In Charging Tray with the front of the
radio facing toward you.
Note: The battery can be charged while inside
the radio or separately. The battery’s
silver contacts must face down and the
Motorola Logo must face the front of
Charger.
The light on the Plug-in Charger will glow
continuously when radio/battery is inserted.
Note: Allow up to 10 hours for the battery to
reach full charge.
13
Drop-In
Charging
Tray
Plug-in
Charger
Pin
