Detailed View - DS5M
The images below depict the standard DS5M enclosure showing the front view with its LED
lights and the rear view with the interface and connections.
Front View
1. 802.11b/g Antenna
2. Infrared Receiver
3. LAN Access LED
X
Y Z [ \
4. USB LED
5. Power LED
Rear View
1. ON/OFF Switch
2. Power Receptacle
3. USB 2.0 downstream port
4. A/V multi connector
5. SPDIF audio connector
6. USB 2.0 upstream ports
7. Ethernet RJ-45 port
8. Micro security slot
X Y Z
[
\
]
^ _
Note: These images are for reference only. Your model may come in a different colour and
without the 802.11b/g antenna.
