DS5 User Guide
5. Turn around the bridge board, insert
the PCI module in the PCI slot on a
slight angle and gently press down on
the PCI module till the side clasps lock
it into place.
6. Remove the plastic cap for the
antenna opening.
7. Insert the antenna into the slot opening
ensuring it is pointing upright and then
place the lock on the internal end of
the antenna to secure it to the unit.
8. Align the bridge board with the body
and connect the antenna cable end to
the “main” connector on the PCI
module.
Page 16 / Chapter 2 - Hardware Installation
