DS5
User Guide
Detailed View - DS5
The images below depict the standard DS5 enclosure showing the front view with its LED
lights and the rear view with the interface and connections.
Front View
1. 802.11b/g Antenna
2. LAN Access LED
3. Infrared Receiver
4. Power LED
X
Y Z [
Rear View
1. ON/OFF Switch
2. Power Receptacle
3. A/V multi connector
4. SPDIF audio connector
5. USB 2.0 upstream ports
6. Ethernet RJ-45 port
7. Micro security slot
X Y
Z
[
\
] ^
Note: These images are for reference only. Your model may come in a different colour and
without the 802.11b/g antenna.
Page 3 / Chapter 1 - Introduction
