Cleaning
7
Cleaning Guidelines
To achieve the best results, cleaning must be regular and
thorough. If any small faults occur, have them looked at
promptly. Don't wait until they cause a complete
breakdown.
NOTE:
• Carefully read and follow the safety instructions on
the label of the cleaning product to be used.
• DO NOT use harsh abrasive scouring pads or
abrasive detergents as they could damage the oven.
• Ensure that any detergent or cleaning material has
been completely removed after each cleaning.
To keep your oven clean and operating at peak efficiency,
follow the procedures shown below:-
Oven Cleaning
NOTE:
• If the oven usage is very high, the cleaning
procedure should be carried out on a more frequent
basis.
• Allow the oven interior to cool to approx 50˚C /
120˚F before commencing cleaning.
Stainless Steel Surfaces
a. Thoroughly clean the exterior surfaces of the oven
with a damp cloth moistened with a mild detergent
solution or a soft bristled brush.
b. Baked on deposits or discolouration may require a
good quality stainless steel cleaner. Always apply
cleaner when the oven is cold and rub in the
direction of the grain.
Side Racks
a. Remove the wire oven racks.
b. Partially undo the rack / baffle securing screw (anti-
clockwise) securing the rack to oven wall, until the
rack is loose.
c. Pull racks forward to disengage the location pins at
the rear of rack from the fan baffle, remove the side
racks from the oven.
d. Clean all racks with a mild anti bacterial detergent
and hot water, using a soft bristled brush.
e. Dry the racks thoroughly with a dry cloth.
f. To refit the racks, engage the locating pins at the
rear of side rack into the locating holes in the fan
baffle at the rear of the oven.
g. At the same time locate the front of the rack over
the rack / baffle securing screw and hand tighten
the rack / baffle securing screw.
h. Refit the wire oven racks to the oven.
Fan Baffle (Not E22M3)
a. Remove side racks as shown previously.
b. Undo (anti-clockwise) and remove the rack / baffle
securing screw at the top of the fan baffle. (E27 /
E28 Ovens, have 2 rack / baffle securing screws).
c. Tilt the fan baffle forward and lift up off the location
brackets at rear of oven.
d. Clean the fan baffle with mild anti bacterial
detergent and a hot water solution using a soft
bristled brush.
e. Dry fan baffle thoroughly with a soft dry cloth
before re-fitting.
f. Refit the fan baffle and hand tighten the rack /
baffle securing screw(s) to secure the fan baffle.
Always turn off electrical power at the
mains supply before commencing cleaning.
This oven is not water proof. Do not use
water jet spray to clean interior or exterior
of the appliance.
Caution
Securing Screw
Location
Brackets
Add Image of location
of Rack Thumbscrew
with rack in place.
Side Rack
Rear
Location
Pins
Fan Baffle
Securing Screw
