Cleaning
9
d. Whilst still holding the oven door in the open
position, clean the inner glass and the inside of the
outer glass with a conventional glass cleaner.
e. Dry the oven glass thoroughly with a soft dry cloth.
f. On completion of door glass cleaning, lower the
inner glass back into the door, the glass will locate
itself in the correct position.
g. Close the oven door.
Door Inner Glass Removal
It is possible to remove the inner glass completely from
the oven door for heavy cleaning. This can be done as
follows:-
a. Open the oven door fully.
b. Using a suitable instrument, move the door lock
catches from the unlocked to the locked position to
prevent the door from closing.
c. Raise the door until it is restrained by the door lock
catches.
d. Grasp the inner glass firmly on either side and pull
upwards to remove the inner glass from the locating
pegs on either side of the door.
Door Inner Glass Re-Fitting
a. To refit the inner glass, locate the 2 locating tabs on
either side of the inner glass into the 2 pegs on the
door and push down on the inner glass until it locks
firmly into position.
b. Lower the inner glass back into the door, the glass
will locate itself in the correct position.
c. Open the oven door fully and u sing a suitable
instrument, move the door lock catches to the
unlocked position.
NOTE: Check that both Door Lock Catches are in the
‘Un-Locked’ position before closing the door.
d. Close the oven door.
Inner Glass
Door Lock Catch in
Unlocked Position
Door Lock Catch in
Locked Position
Locating Tab
Locating Peg
Door Lock Catch in
Unlocked Position
