Chapter 2: Sample System
Multi-Tech Systems, Inc. CF220 CallFinder User Guide 17
Step 4 Technical: Enter operating parameters of CallFinder channel (FXS).
Power
48Vdc
Channel 2 Channel 1 Power
5Vdc
Ethernet
FXS/FXO DID FXS/FXO DID 10/100
CF
220
(Rear)
Channel Configuration: Channel 2
Max DID Digits 4 DID Start wink immediate delay dial
Extension Port FXS FXO Auto Attendant Delay 0
Receive Gain 100 Transmit Gain 100
Polarity A B
Extension Mic Gain 8 Extension Speaker Gain 30
of CallFinder
DID-Channel Modem
Technical Parameters Telco
DID
Outlet
PBX
Station
Port
