17
Getting Star
ted
With Rapid Drop-In Charging Tray
Note: Allow up to 2 hours for the battery to reach full charge.
The Rapid Charger is packaged as an Accessory Kit (Part No. 53875).
The Drop-In Charging Tray can be placed on
any flat surface and provides drop-in charging
convenience.
•
Connect Plug-in Charger and Drop-In
Charging Tray by inserting the pin into the
rear of Drop-In Charging Tray.
• To charge the battery, drop the radio into
the Drop-In Charging Tray with the front of
the radio facing toward you.
Note: The battery (Motorola part numbers
NNTN8971 or NNTN4190) can be
charged while inside the radio or
separately. The battery’s silver contacts
must face down and the Motorola Logo
must face the front of Charger.
The light on the Plug-in Charger will glow
continuously when radio / battery is inserted.
Pin
Drop-In
Charging
Tray
NNTN4075
Plug-in
Charger
2585747D01
