Filling the spray unit
The spray feature ‰ is lightly secured to
the handle. To fill the water tank, pull the
spray unit forward using the two moulded
lugs provided.
Remove the spray bottle  from the base
of the pump and fill with water to the ‘MAX’
mark.
Re-fit the spray bottle, making sure the
arrows (printed black) are in line.
To replace the spray unit
Align the spray unit with the front of the
iron.
Fit the bottom location leg into the slot at
the front of the handle. Pivot the spray unit
towards the iron, making sure it clips firmly in
place.
Anti-scale system
The anti-scale cartridge is designed to
reduce the build-up of limescale which
occurs during steam ironing, this will prolong
the working life of your iron. However, please
note that the anti-scale cartridge will not
completely stop the natural process of
limescale build-up.
Replacing your anti-scale cartridge
How often you need to replace your anti-
scale cartridge depends on how often you
use your iron with it’s steam functions and
how ‘hard’ your water supply is. Water
hardness varies greatly from one area to
another. For advice on the relative hardness
of your water, contact your local water
supplier.
If you spend an average of two hours per
week ironing, then we suggest you refill your
anti-scale cartridge as shown below:
If you iron more or less frequently, then
you should alter the interval between refills
accordingly.
Replacement anti-scale refills
To obtain replacement anti-scale refills,
telephone our spares number on:
0844 873 0719.
1 If a new cartridge is not available, you
may continue operating the appliance but
scale will build up in the system. Replace
the used cartridge as soon as possible.
2 Disconnect the appliance from the mains
outlet.
3 Slide out the tank and remove the
anti-scale cartridge as shown E.
4 Pull the plate from the end of the cartridge
F .
5 Remove the foam pad G.
6 Place the refill into the cartridge,
reposition the foam pad
and clip the plate onto the
cartridge, making sure it
locks in position H.
Features of your
steam generator
Temperature indicator light
The indicator light shows
that the iron is warming up.
When the required temperature is reached,
the light will go out and will cycle on-off
during operation.
Steam function
During the steaming process, small
amounts of water may be ejected from the
soleplate. This is normal and can be avoided
by using the steam for short amounts of time
and only when the iron is at the correct
temperature (the indicator light on the iron
goes out when ready).
6
Water hardness Soft Medium Hard
Refill interval 6 3 1 1/2
(months)
E
F
H
G
