Mercedes-Benz 2004 C-Class Coupe User Manual
Page 323
323
Technical data
Layout of poly-V-belt drive
̄
Layout of poly-V-belt drive
C 230 Kompressor
1 Power steering pump
2 Idler pulley
3 Supercharger
4 Automatic belt tensioner
5 Air conditioning compressor
6 Crankshaft
7 Coolant pump
8 Generator (alternator)
C 320
1 Automatic belt tensioner
2 Power steering pump
3 Air conditioning compressor
4 Crankshaft
5 Coolant pump
6 Generator (alternator)
7 Idler pulley
